An INMENA bucket, piece by piece
Scroll down and see how it is built: from the idea to delivery on site.
- 10 manufacturing stages
- 3D design in Inventor
- Validated by finite element analysis
Stage 01 of 10
Requirements
We start from your machine, the material it loads and the production you need.
Product · Manufacturing
Bucket manufacturing
We design and build your bucket to fit your machine and the material it moves, with engineering validated by simulation.
Fits large mining excavators · EC950E
| Product | Mining excavator bucket, custom-built |
|---|---|
| Compatible machines | EC950E · other models ? |
| Capacity | ? m³ |
| Weight | ≈ 7.9 t (estimated from the 3D model) |
| Width | 2.5 m |
| Steels | ASTM A709 Gr. 50 · 500 BHN wear plate · bimetallic plate |
| Wear protection | 51 liners · corner shrouds · heel shrouds · adapters and teeth |
| Engineering | 3D model in Inventor · finite element analysis |
| Welding | Procedure INM-SOL-OP2 with heat-input control |
| Quality control | NDT · dimensional · dossier ? |
| Lead time | ? |
| Warranty | ? |
Your request goes straight to our Sales team.
Illustrative 3D model. The design and drawings are the property of INMENA S.A.C. © 2026. Reproduction prohibited.
